Detail Ubiquiti RD-5G31-AC Rocket Dish AC 5GHz 31dBi

The Ubiquiti RocketDish 5G31AC is a Carrier Class Dish Antenna that was designed to seamlessly integrate with Rocket M radios (sold separately).

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Ubiquiti RocketDish Key Features
AirMax Carrier Class 2x2 PtP Bridge Dish Antenna
Models: RD-5G-30, RD-5G-34, RAD-2RD (Radome Only), RAD-3RD (Radome Only)
Ultimate in RF Performance
Integrated Mount lets you easily snap Rocket M into place
Product Model Number: RD-5G31-AC
Rocket M combines the two brains in one robust unit; pair Rocket M with Ubiquiti RocketDish to create powerful 2x2 MIMO PtP bridging applications. This seamless integration gives network architects unparalleled flexibility and convenience.

Specifications
RocketDish RD-5G31-AC

Dimensions

748 x 748 x 349 mm (29.45 x 29.45 x 13.74")

Weight

7.6 kg (16.76 lb)

(Mount Included)

Frequency

5.1 - 5.8 GHz

Gain

31 dBi

Max. VSWR

1.4:1

Wind Survivability

200 km/h (125 mph)

Wind Loading

1,028 N @ 200 km/h (231 lbf @ 125 mph)

Polarization

Dual Linear

Cross-Pol Isolation

35 dB Min.

ETSI Specification

EN 302 326 DN2

Mounting

Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included
