Ubiquiti PBE 5AC 500 ISO PowerBeam 5Ghz AC 500 ISO 27dBi

Detail Ubiquiti PBE 5AC 500 ISO PowerBeam 5Ghz AC 500 ISO 27dBi

Specifications

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

PBE-5AC-500-ISO

Dimensions 564 x 564 x 308 mm (22.20 x 22.20 x 12.13")

Weight 5.2 kg (11.5 lb)

Power Supply 24V, 0.5A Gigabit PoE

Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)

Supported Voltage Range 20-26VDC

Max. Power Consumption 8W

Operating Frequency Worldwide USA: U-NII-1 USA: U-NII-2A USA: U-NII-2C USA: U-NII-3

5150 - 5875 MHz 5150 - 5250 MHz* 5250 - 5350 MHz* 5470 - 5725 MHz* 5725 - 5850 MHz*

Gain 27 dBi

Networking Interface (1) 10/100/1000 EthernetPort

Processor Specs Atheros MIPS 74Kc, 720 MHz

Memory 128 MB DDR2, 16 MB Flash

LEDs (1) Power, (1) LAN, (4) WLAN

Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels

Channel Sizes PtP Mode PtMP Mode

10/20/30/40/50/60/80 MHz 10/20/30/40 MHz

Max. VSWR 1.5:1

Built-In Mechanical Downtilt 20

Polarization Dual Linear

Enclosure Outdoor UV Stabilized Plastic

Mounting Pole-Mount Kit Included

Wind Loading 984 N @ 200 km/h (221.2 lbf @ 125 mph)

Wind Survivability 200 km/h (125 mph)

ESD/EMP Protection Air: 24 kV, Contact: 24 kV

Operating Temperature -40 to 70 C (-40 to 158 F)

Operating Humidity 5 to 95% Noncondensing

Wireless Approvals FCC, IC, CE

RoHS Compliance Yes

Gambar produk
