Ubiquiti Nano Switch Outdoor 4-Port POE Passthrough Switch N-SW

Detail Ubiquiti Nano Switch Outdoor 4-Port POE Passthrough Switch N-SW

Garansi Resmi Ubiquiti 1 Tahun

Ubiquiti Nano Switch (N-SW)

Simply providing 24V 2-pair input makes NanoSwitch an outdoor 4-port unmanaged switch with "always on" 24V 2-pair output on three ports.

Deskripsi Ubiquiti Nano Switch Outdoor 4-Port POE Passthrough Switch N-SW
The Ubiquiti NanoSwitch is an unmanaged switch with four Gigabit Ethernet ports. For its total non‑blocking line rate, the Ubiquiti NanoSwitch supports up to 4Gbps.

Product Features

• 4-PoE Ports
• Poe In: RJ45 port supports 10/100/1000 Ethernet connections, and supports 24V passive PoE to power the switch.
• PoE Out 1-3: RJ45 ports support 10/100/1000 Ethernet connections, and the three 24V passive PoE ports provide up to 36W PoE output.

Product Specifications

• Dimensions (Excluding Mount): 196.4 x 93.5 x 32.4 mm / ( 7.73 x 3.68 x 1.28")
• Weight: 271g / (9.6oz)
• Enclosure: White Polycarbonate
• Networking Interfaces: (4) 10/100/1000 Mbps Ethernet RJ45
• Supported Voltage Range: Passive 24V PoE In
• Power Method: Passive 24V PoE In
• Passive PoE Max Wattage per Port: 24V, 1A per Port (24W)
• Total Passive PoE Max Wattage: 24V, 1.5A for 3 Ports (36W)
• Total Non-Blocking Line Rate: 4 Gbps
• Typical Power Consumption: 1.5W
• Operating Temperature: -30 to 70° C / (-22 to 158° F)
• Operating Humidity: 5 to 95% Noncondensing
• ESD/EMP Protection: ± 24kV Air, ± 24kV Contact
• Certifications: CE, FCC, IC

Product Includes

• Ubiquiti NanoSwitch
• Self Tapping Screws
• Metal Straps (Qty: 2)
• Quick Start Guide
