UBiquiti Lite Beam M5 23 Lbe M5 23 Litebeam M5 23dbi

Detail UBiquiti Lite Beam M5 23 Lbe M5 23 Litebeam M5 23dbi

Lite Beam M5-23 Litebeam M5-23 litebeam M5 23
The LiteBeam is the latest evolution of a lightweight and compact, outdoor wireless broadband product from Ubiquiti Networks. Each of these models was designed to be an affordable cost/performance solution for long-distance, wireless broadband bridging. It operates in the worldwide, license-free 5 GHz frequency range with high-performance speeds. The LiteBeam combines proprietary hardware and software technologies to deliver its breakthrough combination of throughput and range with cost-effective value. The InnerFeed technology (models LBE-M5-23 and LBE-5AC-23) integrates the entire radio system into the antenna feed, and our revolutionary airMAX TDMA protocol enhances network performance and scalability
Kode Item/Barang : LBE-M5-23

Deskripsi
Specification
Transmission speed max (Mbps) 100
Standards 802.11a/n
Chipset Atheros
TX Power regulation ano
Max. output power (dBm) 25
Sensitivity (dBm) -94
Guaranteed lifetime (h) 8000
Modulation OFDM, QAM
Encryption WPA-AES, WPA2-AES
LAN port 1x RJ45 10/100Mbps
Default IP 192168120
Default name ubnt
Default password ubnt
Mounting kit for mast
Interface LAN, WiFI
Consuption (W) 4
Gain (dBi) 23
SWR 1 ,5
Procesor Atheros MIPS 74KC, 560 MHz
RAM (MB) 64
Weight (kg) 3
IPv6 support Transparent (BRIDGE mode)
Height (mm) 267
Width (mm) 362
Depth (mm) 184
Powering max (PoE) (V) 25
Min. operating temperature (C) -40
Max. operating temperature (C) 70.
#UBiQUiTi

Gambar produk
