EdgeRouter X SFP
ER-X-SFP

The EdgeRouter™ X SFP combines cost-effective routing performance with the convenience of passive PoE support in a compact form factor.

(5) Gigabit RJ45 ports with passive PoE support
(1) Gigabit SFP port for backhaul applications
Ports configurable for line-rate, Layer-2 switching
130 kpps for 64-byte packets
1 Gbps for 1518-byte packets

EdgeRouter
Dimensions 142 x 75 x 23 mm (5.59 x 2.95 x 0.91")
Weight 215 g (7.58 oz)
Max. Power Consumption 5W
Power Input 24VDC, 2.5A Power Adapter (Included)
Power Supply External AC/DC Adapter
Supported Voltage Range 9 to 26VDC
Buttons Reset
LEDs Power, Link/Activity (6), PoE (5)
Processor Dual-Core 880 MHz, MIPS1004Kc
Memory 256 MB DDR3 RAM
Code Storage 256 MB NAND
Certifications CE, FCC, IC
Wall Mount Yes
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Networking Interfaces
Data/PoE Input Port (5) 10/100/1000 RJ45 Ports
Data Port (1) 100/1000 SFP Port
PoE with 24VDC Power Adapter
PoE Out Voltage Range 22-24VDC
Max. PoE Wattage Per Data Port 12W (24V)
Max. PoE Wattage Combined for All 5 Data Ports 50W
PoE Method Passive
