2K HD, 30 FPS camera with a 5MP CMOS sensor View angle (84.4˚) Weatherproof IPX4-rated enclosure Flexible, three-axes adjustment Improved low-light performance and IR night vision up to 10m
Managed with the UniFi Protect application: Version 2.2.7 or 2.7.18 and later (web) / 1.10.0 and later (mobile)
Mechanical Dimensions Without mount: Ø75.5 x 74.4 mm (Ø2.97 x 2.93") With wall mount: Ø75.5 x 150 mm (Ø2.97 x 5.9") Weight Without mount: 225 g (7.94 oz) With wall mount: 315 g (11.11 oz) Enclosure materials Polycarbonate, aluminum alloy Mount materials Wall mount: aluminum alloy, polycarbonate Pole mount: aluminum alloy Weatherproofing IPX4 Resistance IK04 Optics Sensor 5 MP CMOS sensor Lens Fixed focal length View angle H: 84.4°, V: 45.4°, D: 99.8° Night mode Built-in IR LED illumination and IR cut filter Video Video compression H.264, MJPEG Resolution 2688 x 1512 (16:9) Max. frame rate 30 FPS Image settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay System Processor specs Dual-core Arm® Cortex®-A7 based chip Networking interface 10/100 MbE RJ45 port Max. power consumption 4W Power method PoE Supported voltage range 37—57V DC Button Factory reset Mounting Wall, pole mount Operating temperature -20 to 40º C (-4 to 104º F) Operating humidity 0 to 90% noncondensing Certifications FCC, IC, CE Audio Microphone Yes (Can be disabled in software) Software UniFi OS application UniFi Protect Mobile app UniFi Protect iOS™ and Android™
