Ubiquiti AM-5G16-120 Antena Airmax Sectoral|AM5G16-120|AM 5G16 120

Merek: Ubiquiti Networks | Lihat selengkapnya produk Komputer & Aksesoris dari Ubiquiti Networks
Komputer & Aksesoris > Komponen Network > Komponen Network Lainnya > Ubiquiti AM-5G16-120 Antena Airmax Sectoral|AM5G16-120|AM 5G16 120
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Ubiquiti AM-5G16-120 Antena Airmax Sectoral|AM5G16-120|AM 5G16 120

Ubiquiti AM-5G16-120 Airmax Sector Antenna

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Specifications
AM-5G16-120
Dimensions 367 x 63 x 41 mm
Weight (Mount Included) 1.1 kg (2.43 lb)
Frequency AM-5G16-120 : 5.10 - 5.85 GHz
Gain AM-5G16-120 : 15.0 - 16.0 dBi
HPOL Beamwidth AM-5G16-120 : 137 (6 dB)
VPOL Beamwidth AM-5G16-120 : 118 (6 dB)
Elevation Beamwidth 8
Electrical Downtilt 4
Max. VSWR 1.5:1
Wind Survivability 200 km/h (125 mph)
Wind Loading 41.7 N @ 200 km/h (9.375 lbf @ 125 mph)
Polarization Dual Linear
Cross-Pol Isolation 22 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, Rocket Bracket, and
Weatherproof RF Jumpers Included
