Ubiquiti Airfiber AF-5U |AirFiber 5U AF5U

Detail Ubiquiti Airfiber AF-5U |AirFiber 5U AF5U

SKU :13060003

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Ubiquiti Networks AF-5U 5 GHz
HARGA 1 UNIT

Max. Power Consumption 40W
Power Supply 50V, 1.2A PoE GigE Adapter (Included)
Power Method Passive Power over Ethernet
Supported Voltage Range +42 to +58VDC, -48VDC
Automatic Transmit Power Control (ATPC) Yes
Certifications CE, FCC, IC
Mounting Pole Mount Kit (Included)
Wind Loading 863 N @ 200 km/hr (194 lbf @ 125 mph)
Wind Survivability 200 km/hr (125 mph)
Operating Temperature -40 to 55° C (-40 to 131°F)
LEDs (12) Status LEDs:
Data Port Link/Activity
Data Port Speed
Management Port Link/Activity
Management Port Speed
GPS Synchronization
Master/Slave
Link Status
Modulation Mode 0.25x to 4x, 6x, 8x, 10x (Unlabeled), Overload
Remote and Local Displays (Calibrated Signal Strength)
Operating Frequency
AF-5
FCC 15.247, 15.407, IC RSS-210
ETSI EN 301 893, EN 302 502
Other Regions
5470 - 5600 MHz, 5650 - 5850 MHz
5470 - 5875 MHz
5470 - 5950 MHz
AF-5U
FCC 15.247, IC RSS-210
ETSI EN 302 502
Other Regions
5725 - 5850 MHz
5725 - 5875 MHz
5725 - 6200 MHz
Interface
Data Port (1) 10/100/1000 Ethernet Port
Management Port (1) 10/100 Ethernet Port
Auxiliary Port (1) RJ-12, Alignment Tone Port
System
Maximum Throughput 1.2+ Gbps
Maximum Range 100+ km (Dependent on Regulatory Region)
Packets per Second 1+ Million
Encryption 128-Bit AES
Uplink/Downlink Ratio 50% Fixed
Latency
Full Duplex Mode
Half Duplex Mode
< 200 µs at Full Throughput
< 2 ms at Full Throughput
Radio Frame Synchronization GPS
Dynamic Frequency Selection
AF-5
AF-5U
CE, FCC/IC
CE (FCC/IC Not Applicable)
MTU (Maximum Transmission Unit) Up to 9600

Gambar produk
