TPLINK TL-WPA4230KIT AV500 Passthrough Power line Wi-Fi Kit

Detail TPLINK TL-WPA4230KIT AV500 Passthrough Power line Wi-Fi Kit

HARDWARE FEATURES
Plug Type EU, UK, FR
Standards and Protocols HomePlug AV, IEEE1901, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n
Interface 3*10/100Mbps Ethernet Ports
Button Pair, Reset, Wi-Fi/Wi-Fi Clone
LED Indicator PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone
Dimensions ( W x D x H ) 5.0 x 2.5 x 1.7 in. (126 × 64 × 42mm)
Range 300 Meters over electrical circuit
WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Transmit Power CE:<20dBm(2.4GHz)
FCC:<30dBm
Wireless Functions Enable/DisableWireless Radio,WMM, Wireless Statistics
Wireless Security 64/128-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
SOFTWARE FEATURES
Modulation Technology OFDM (PLC)
Encryption Powerline Security:
128-bit AES
Wireless Security:
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption
OTHERS
Certification CE, FCC, RoHS
Package Contents Powerline Ethernet Adapter TL-WPA4230P&TL-PA4020P
Resource CD
Quick Installation Guide
2-meter RJ-45 Ethernet Cable * 2
System Requirements Windows 8/7/Vista/XP/2000, Mac OS X, Linux-based operating system
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
