TPLink EAP225 Outdoor, AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point TP-Link EAP-225

Detail TPLink EAP225 Outdoor, AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point TP-Link EAP-225

TPLink EAP225 Outdoor,AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point

TPLink EAP225-Outdoor AC1200 Dual Band Outdoor Access Point
Qualcomm, 867Mbps at 5GHz + 300Mbps at 2.4GHz
1 Gigabit LAN
802.3af PoE and Passive PoE, 2 External Antennas
IP65 Weatherproof, MU-MIMO, Band Steering
Beamforming, Airtime Fairness, Centralized Management
Captive Portal
Load Balance
Rate Limit
VLAN

Durable, weatherproof enclosure for outdoor Wi-Fi applications
Up to 1200Mbps1 with 2×2 MIMO technology
Omada Mesh Technology enables wireless connectivity between APs for extended range, making wireless deployments more flexible and convenient
Supports Seamless Roaming to smooth the video playbacks and voice calls when moving between locations
High transmission power and high gain antennas provide a long-range coverage area
Cloud centralized management and Omada app for ultra convenience and easy management
Captive portal provides a convenient method for guest authentication
Facebook Wi-Fi and SMS authentication help to boost your business
802.3af/Passive PoE (PoE Adapter Included) compatible and simple mounting design allow for flexible deployment and convenient installation

Specifications :
HARDWARE FEATURES
Interface = 1x Gigabit Ethernet RJ-45 port
Button = Reset
Power Supply = 802.3af PoE and 24 Passive PoE(PoE injector included)
Power Consumption = 10.5W
Dimensions ( W x D x H ) =8.5 × 1.8 × 1.1in. (215 × 46 × 27 mm)
Antenna = 2.4GHz: 2 × 3dBi , 5GHz: 2 × 4dBi
Weatherproof Enclosure = IP65
Mounting = Pole/Wall mount (mounting kit included)

WIRELESS FEATURES
Wireless Standards IEEE 802.11a/b/g/n/ac
Frequency 2.4GHz, 5GHz
Signal Rate 802.11ac: 5G:6.5 Mbps to 867Mbps(MCS0-MCS9,NSS = 1 to 2 VHT20/40/80) 2.4G:78Mbps to 300Mbps (MCS8-MCS9 VHT20/40, NSS=1 to 3)
802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 5.5, 11Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Functions Multiple SSIDs（Up to 16 SSIDs, 8 for each band）
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control （Adjust Transmit Power on dBm）
QoS(WMM)
MU-MIMO
Airtime Fairness
Beamforming
Band Steering
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
Transmission Power • CE: <20 dBm (2.4 GHz, EIRP), <27 dBm(5 GHz, EIRP)
• FCC: <23 dBm (2.4 GHz), <22 dBm(5 GHz)
MANAGEMENT
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Omada Controller Software Yes
Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Email Alerts Yes
Management MAC Access Control Yes
