Detail TPA3110D2 TPA3110 Audio IC Power Chip Tssop28 SMD

Untuk LED Polytron & Toshiba, dll.
TPA3110D2 TPA3110 Audio IC power chip TSSOP28 SOP28 SMD AZ17
Description:
The TPA3110D2 is a 15-W (per channel) efficient, Class-D audio power amplifier for driving bridged-tied stereo speakers. Advanced EMI Suppression Technology enables the use of inexpensive ferrite bead filters at the outputs while meeting EMC requirements. SpeakerGuard speaker protection circuitry includes an adjustable power limiter and a DC detection circuit. The adjustable power limiter allows the user to set a "virtual" voltage rail lower than the chip supply to limit the amount of current through the speaker. The DC detect circuit measures the frequency and amplitude of the PWM signal and shuts off the output stage if the input capacitors are damaged or shorts exist on the inputs.

Feature:
15-W/ch into an 8- Loads at 10% THD+N From a 16-V Supply
10-W/ch into 8- Loads at 10% THD+N From a 13-V Supply
30-W into a 4- Mono Load at 10% THD+N From a 16-V Supply
90% Efficient Class-D Operation Eliminates Need for Heat Sinks
Wide Supply Voltage Range Allows Operation From 8 V to 26 V
Filter-Free Operation
SpeakerGuard Speaker Protection Includes Adjustable Power Limiter Plus DC Protection
Flow Through Pin Out Facilitates Easy Board Layout
Robust Pin-to-Pin Short Circuit Protection and Thermal Protection With Auto Recovery Option
Excellent THD+N / Pop-Free Performance
Four Selectable, Fixed Gain Settings
Differential Inputs
