TP LINK TL SG1005P Switch Hub Gigabit 5 Port PoE Switch N10

Detail TP LINK TL SG1005P Switch Hub Gigabit 5 Port PoE Switch N10

TP-LINK TL-SG1005P Gigabit PoE Switch

SPECT:
Interface 5 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
External Power Supply External Power Adapter(Output: 48VDC / 1.25A)
PoE Ports (RJ45) Standard: 802.3 af compliant
PoE Ports: Port1- Port4
Power Supply: 56W
Backbound Bandwidth 10Gbps
Mac Address Table 2K
Dimensions ( W x D x H ) 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm)
Max Power Consumption 3.95W(220/50Hz. no PD connected)
64.44W(220/50Hz. with 55W PD connected)
Max Heat Dissipation 13.48BTU/h(no PD connected)
219.87BTU/h(with 56W PD connected)
SOFTWARE FEATURES
Advanced Features Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE 802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transfer Method Store-And-Forward
