TP LINK TD-W8151N 150Mbps Wireless N ADSL2+

Detail TP LINK TD-W8151N 150Mbps Wireless N ADSL2+

TD-W8151N

- High speed DSL modem, 1-port NAT router and wireless N access point in one device
- Wireless N speed up to 150Mbps makes it great for online gaming, Internet call and video streaming
- Easy Setup Assistant with multi-language support hassle free installation
- QoS engine enables smooth IPTV streaming and lag-free online gaming
- Supports the latest Internet Protocol IPv6 to future-proof your network

HARDWARE FEATURES
Interface
1 RJ11 DSL Port
1 10/100Mbps RJ45 Port
Button 1 Power On/Off Switch
1 WPS Button
1 Reset Button
1 Wi-Fi On/Off Button
External Power Supply 9VDC/0.6A
IEEE Standards IEEE 802.3, 802.3u
ADSL Standards Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1() Annex A, ITU-T G.992.2() Annex A,ITU-T G.994.1 ()
ADSL2 Standards ITU-T G.992.3 () Annex A/L/M, ITU-T G.992.4 () Annex A
ADSL2+ Standards ITU-T G.992.5 Annex A/L/M
Data Rates Downstream: Up to 24Mbps
Upstream: Up to 3.5Mbps (With Annex M Enabled)
Dimensions ( W x D x H ) 7.14.91.4 in.(mm)
Antenna Type Omni directional, Fixed

WIRELESS FEATURES
Wireless Standards IEEE 802.11g, 802.11b, with some n features
Frequency 2.400-2.4835GHz
Signal Rate 11N: Up to 150Mbps (dynamic)
Transmit Power 20dBm ()
Wireless Security Provides 64/128-bit WEP encryption security and wireless LAN ACL(Access Control List), WPA-PSK/WPA2-PSK authentication and TKIP/AES encryption security

SOFTWARE FEATURES
Quality of Service QoS Remarking based on IPP/ToS, DSCP and 802.1p
Security NAT and SPI Firewall
MAC / IP / Application / URL Filtering
Denial of Service(DoS), SYN Flooding, Ping of Death
Management Web Based Configuration(HTTP), Remote management, Telnet management,
Command Line Interface,
SSL for TR-069, SNMP v1/2c, SNMP over EOC,
Web Based Firmware Upgrade, CWMP(TR-069), Diagnostic Tools
ATM/PPP Protocols ATM Forum UNI3.1/4.0 PVC (up to 8PVCs)
ATM Adaptation Layer Type 5 (AAL5)
ATM QoS (Traffic Shaping)
Bridged and routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (RFC2516)
PPP over ATM (RFC 2364)
IPoA (RFC1577/2225)
Advanced Features DHCP (Dynamic Host Configuration Protocol), DHCP relay
NAT (Network Address Translation)
Static Routing, RIP v1/v2
VPN(PPTP, L2TP, IPSec) Pass-through
PVC/Ethernet Port Mapping
VLAN, 802.1P
DNS Relay, DDNS
IGMP Multicast, IGMP snooping V1/2
Virtual server, DMZ, ACL(Access Control List)
UPnP

OTHERS
Certification CE, FCC, RoHS
Environment Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
