Up to 20 km transmission distance with 9/125 μm SMF (Single-Mode Fiber) Bidirectional WDM communication on a single fiber Compatible with Small Form Pluggable Multi-Source Agreement (SFP-MSA) Supports Digital Diagnostic Monitoring (DDM) Hot-swappable module design Work with TL-SM321B as a pair
HARDWARE FEATURES DDM Yes SFP-MSA Yes Hot Swappable Yes
MEDIA CONVERTER & MODULE Standards and Protocols IEEE 802.3z, TCP/IP Wave Length TX: 1550 nm RX: 1310 nm Power Supply 3.3 V Safety & Emission FCC, CE Cabel Single-Mode Fiber Fiber Type 9/125 μm Single-Mode Max. Cable Length 20 KM Data Rate 1.25 Gbps Port Type LC Simplex Environment Operating Temperature: 0–70 °C (32–158 °F) Storage Temperature: -40–85 °C ( -40–185 °F) Operating Humidity: 10–90% RH, Non-Condensing Storage Humidity: 5–90% RH, Non-Condensing
