TOTO Link CP450 Wireless Outdoor 450Mbps AP/Client|CP450 CPE

Detail TOTO Link CP450 Wireless Outdoor 450Mbps AP/Client|CP450 CPE

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

CP450 Wireless Outdoor CPE is specially designed for outdoor wireless transmission in villages, factories, parks, public squares and other outdoor areas.
With built-in high-gain polarized antennas and high RF output power configuration, CP450 supports point-to-point transmission, point-to-multipoint transmission and wide range outdoor wireless coverage.
CP450 provides multiple working modes, which can be used in various outdoor situations.
Meanwhile, CP450 supports Passive PoE power supply, enabling the installation and wiring more flexible in the outdoor.
With professional protection design on shell, it is dust-proof, water-proof and lightning-proof, suitable for any kinds of severe climate, ideal for Wi-Fi transferring over long distance in the outdoor environment.
Hardware Interface

- 1 *10/100Mbps Port (WAN/LAN, Passive PoE in)
- 1 *10/100Mbps Port (LAN, Passive PoE in)
- 1*Power Port
Power Supply
- 24V Passive PoE / 12VDC/2A
- Voltage range: 12-24VDC

Button
- 1 *RESET Button
Antenna
- 1 *Built-in 12dBi dual polarized antennas
LED Indicators
- 1 *MODE,
- 1 *Power,
- 1 *WAN/LAN,
- 1 *LAN,
- 4 *Signal Strength
Dimensions（L X W X H）
- 237.5 x 79 x 58.5mm

Wireless Standards
- IEEE 802.11n,
- IEEE 802.11g,
- IEEE 802.11b,
- IEEE 802.3,
- IEEE 8.3,
- IEEE 8.3ab,
- IEEE 8.3at

RF Frequency
- 5.15~5.825GHz

Data Rate
- Up to 450Mbps

EIRP - < 23dBm
Wireless Security
- 64/128-bit WEP, WPA/WPA2/WPA-PSK/WPA2-PSK

Reception Sensitivity
- 11n(HT20): -68 dBm@10% PER
- 11n(HT40): -65 dBm@10% PER
- 11a: -72 dBm@10% PER
- 11ac(VHT80): -55 dBm@10% PER

Software

Operation Mode
- Access Point
- Repeater Mode
- Client Mode
- WISP Mode
MIMO Type
- 5G 1Tx-1Rx
Management
- Save/Reset Settings,
- Firmware upgrade,
- System Log

Reliability - 4KV Lightning Protection
- 15KV ESD Protection
- IP65 level dustproof and waterproof

Others
Package Contents
- CP450 Wireless CPE *1
- Power Adapter *1
- User Guide *1
- Ethernet Cable *1
- Strips*2
