TM70B PON Power meter + VFL + Optical Power Meter Optic Fiber Test

Komputer & Aksesoris > Komponen Network > Komponen Network Lainnya > TM70B PON Power meter + VFL + Optical Power Meter Optic Fiber Test
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:SiatrastoreLihat semua produk Komputer & Aksesoris oleh Siatrastore
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail TM70B PON Power meter + VFL + Optical Power Meter Optic Fiber Test

TM70B PON Power meter + 1MW VFL + Optical Power Meter Optic Fiber Test Tools

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Smallest, Lightest and Fastest
Simultaneously verifies the power levels of all wavelengths of PON (1310nm, 1490 nm and 1550 nm)
Pass/fail analysis helps user quickly interpret results and ensures consistent PON network turn-up
Dust and shock proof design
Auto shut off function
Reliable basic functions for the most economic test
Dimension: 16.5X10X5mm
8,10pcs measurement items can be saved in PON power meter or computer for data review.



Standard wavelengths
1310 (upstream)
1490 (downstream)
1550 (downstream)
Pass zone(nm)
1260~1360
1470~1505
1535~1570
Isolation @1310nm(dB)
+15 ~ -35 cw
+8 ~ - 30 bw
Isolation @1490nm(dB)
+10 ~ - 50
+10 ~ - 50
Isolation @1550nm(dB)
+25 ~ - 45
+25 ~ - 45
Accuracy
Uncertainty(dB)
±0.5
Polarization Dependent Loss (dB)
<±0.25
Linearity(dB)
±0.1
Through Insertion Loss(dB)
<1.5
Resolution
0.01dB
Unit
dBm/xW
