P/N CA-1P4-00M1WN-00 Series H Series Model H550 TG ARGB CASE TYPE Middle tower Dimension (H x W x D) 441 x 225 x 472 mm (17.36 x 8.85 x 18.58 inch) Net Weight 7.65 kg / 16.87 lb SIDE PANEL 4mm Tempered Glass x1 Color Exterior & Interior : Black MATERIAL SPCC COOLING SYSTEM Rear (exhaust) : 1 x 120 x 120 x 25mm Addressable RGB fan (1000rpm, 27.2 dBA) Drive Bays -Accessible -Hidden
2 x 3.5“ or 2.5” (HDD Rack); 2 x 2.5” (HDD Bracket) EXPANSION SLOTS 7+2 MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) I/O Port USB 3.0 x 1, USB 2.0 x 2, HD Audio x 1, RGB Switch x 1 PSU Standard PS2 PSU (optional) FAN SUPPORT Front: 3 x 120mm, 2 x 140mm Top: 2 x 120mm, 2 x 140mm Rear: 1 x 120mm, 1 x 140mm RADIATOR SUPPORT Front: 1 x 280mm, 1 x 360mm Top: 1 x 240mm Rear: 1 x 120mm CLEARANCE CPU cooler height limitation: 165mm PSU length limitation: 160mm(With HDD Rack) 200mm(Without HDD Rack) VGA length limitation: 300mm VGA width limitation(Vertically): 45mm RAM height limitation: 40mm(With radiator series)
