Thermaltake Casing Level 20 XT E-ATX Cube Case

Merek: Thermaltake | Lihat selengkapnya produk Komputer & Aksesoris dari Thermaltake
Komputer & Aksesoris > Komponen Desktop & Laptop > Casing Komputer > Thermaltake Casing Level 20 XT E-ATX Cube Case
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Thermaltake Casing Level 20 XT E-ATX Cube Case

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

Level 20 XT
CA-1L1-00F1WN-00

E-ATX cube chassis with four 4mm think tempered glass panels and one preinstalled 140mm rear fan.

P/N
CA-1L1-00F1WN-00

Series
Level 20

Model
Level 20 XT

CASE TYPE
E-ATX Cube Case
Dimension (H x W x D)
515 x 394 x 662 mm
(20.3 x 15.5 x 26.06 inch)

NET WEIGHT
20.4 kg / 44.97 lb

SIDE PANEL
4mm Tempered Glass x 4(Left & Right & Front & Top)

Color
Exterior & Interior : Black

MATERIAL
SPCC

COOLING SYSTEM
Rear (exhaust) :
140 x 140 x 25 mm fan (1000rpm, 16dBA)
Drive Bays
-Accessible
-Hidden
6 x 3.5’’ or 2.5’’ (HDD Cage)
1 x 3.5’’, 2 x 2.5’’ (M/B Tray)

EXPANSION SLOTS
8

MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (Extend ATX)

I/O Port
USB 2.0 x2, USB 3.0 x2, HD Audio x 1, Type-C x1

PSU
Standard PS2 PSU (optional)

FAN SUPPORT
Front:
3 x 120mm, 2 x 140mm, 2 x 200mm
Top:
8 x 120mm, 6 x 140mm, 2 x 200mm
Rear:
2 x 120mm or 2 x 140mm
Bottom:
3 x 120mm
Left / Right Side:
4 x 120mm, 3 x 140mm

RADIATOR SUPPORT
Front:
1 x 120mm or 1 x 240mm or 1 x 360mm
1 x 140mm or 1 x 280mm
Top:
2 x 120mm or 2 x 240mm or 2 x 360mm or 2 x 480mm
2 x 140mm or 2 x 280mm or 2 x 420mm
Rear:
1 x 120mm or or 1 x 140mm
Left / Right Side:
1 x 120mm or 1 x 240mm or 1 x 360mm or 1 x 480mm
1 x 140mm or 1 x 280mm or 1 x 420mm
Bottom:
1 x 120mm or 1 x 240mm or 1 x 360mm or 1 x 480mm
1 x 140mm or 1 x 280mm or 1 x 420mm

CLEARANCE
CPU cooler height limitation:
250mm
VGA length limitation:
400mm(with ODD cage)
590mm(without ODD cage)
PSU length limitation:
220mm (With Bottom Fan)
