Terminal Block 8P 3.81mm Plugable 8 Pin Bengkok Plug-in Connector PCB

Elektronik > Perangkat Audio & Speaker > Kabel & Konverter Audio & Video > Terminal Block 8P 3.81mm Plugable 8 Pin Bengkok Plug-in Connector PCB
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:RAFTECHLihat semua produk Audio oleh RAFTECH
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail Terminal Block 8P 3.81mm Plugable 8 Pin Bengkok Plug-in Connector PCB

Pembelian 1 pasang ya gan

Care Clamp: Brass, Ni Plated
Wire guard: Phosphor Brass, Tin Plated
Housing:PA66, UL94V-0
Screws: M2.0 steel Zinc plated
Color: Green

Environmental:
Operation Temperature: -40oC~+150oC
Short-time Temperature: +250oC for 5 sec

Electrical Data:
Rated Voltage: 300V
Rated Current: 12A
Contact Resistance:20mΩ
Insulation Resistance:>5000MΩ DC500V
Withstanding Voltage: AC2000V/1min
Wire range: 28-14AWG 1.5mm²
Strip lengath:6-7mm
