Tenda TEG5328F 24 Port L3 Managed Switch

Merek: Tenda | Lihat selengkapnya produk Komputer & Aksesoris dari Tenda
Komputer & Aksesoris > Komponen Network > Switch Internet & PoE > Tenda TEG5328F 24 Port L3 Managed Switch
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Tenda TEG5328F 24 Port L3 Managed Switch

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

Model
TEG5328F
Network standard
IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3ad、 IEEE802.3z、 IEEE802.3x、IEEE802.1p、 IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s
LED indicator
One Link/Act LED indicator for each port
One Power LED indicator for each device
One SYS LED indicator for each device
Interface
24 x 10/100/1000 Base-T Ethernet ports
4 x 1000 Base-X SFP ports
1 x Console port
Fan Quantity
None
Level of protection
Lightning protection for ports: ≥6kV (common mode)
Lightning protection for power: ≥6kV (common mode), ≥4kV (differential mode)
ESD:
Air discharge: ±8kV
Contact discharge: ±6kV
Forwarding Mode
Store-and-forward
Switching Capacity
56Gbps
Packet Forwarding Rate
41.7Mpps
Buffer
12Mb
MAC Address Learning
16K
Jumbo Frame
10K
PoE power supply
N/A
PoE budget
N/A
Input Voltage
100-240V AC 50/60Hz
Power Consumption
Full load: <24W
Empty load: <10W
Dimension
440 mm x 178.8 mm x 44 mm(L*W*H)
Mounting options
Desktop mounting
Rack mounting (19" 1U)
Wall mounting
Energy Efficient
Support
Environment
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing
Certification
CCC、FCC、CE、RoHS
L3 Features
Supports VLAN-based routing
Supports IPv4 static routing
Supports static ARP
Security features
ARP receiving limit
Unknown MAC address discard
DoS attack defense
802.1x security authentication
Radius authentication
VLAN
IEEE 802.1Q VLAN
VLAN Layer-3 interfaces
Supports three port modes: Access, Trunk and Hybrid
DHCP
DHCP Relay
DHCP Snooping
Supports Option 82 policy configuration
Port Aggregation
