TENDA TEG5312F L3 Managed Switch

Detail TENDA TEG5312F L3 Managed Switch

Terima kasih Sudah berkunjung di Kurnia Abadi Semesta.
Demi kenyamanan bersama terkait harga, stock, warna, dll, harap konfirmasi terlebih dahulu sebelum order.
Terima kasih

Model
TEG5312F
Network standard
IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3ad、 IEEE802.3z、 IEEE802.3x、IEEE802.1p、 IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s
LED indicator
One Link/Act LED indicator for each port
One Power LED indicator for each device
One SYS LED indicator for each device
Interface
10 x 10/100/1000 Base-T Ethernet ports
2 x 1000 Base-X SFP ports
Fan Quantity
NA
Level of protection
Lightning protection for ports: ≥6kV (common mode)
Lightning protection for power: ≥6kV (common mode), ≥4kV (differential mode)
ESD:
Air discharge: ±8kV
Contact discharge: ±6kV
Forwarding Mode
Store-and-forward
Switching Capacity
24Gbps
Packet Forwarding Rate
17.9Mpps
Buffer
12Mb
MAC Address Table
16K
Jumbo Frame
10K
PoE budget
N/A
Input Voltage
100-240V AC 50/60Hz
Power Consumption
Full load: ＜19W
Empty load: ＜9W
Dimension
294 mm x 179.6 mm x 44 mm(L*W*H)
Mounting
Desktop mounting
Rack mounting (13" 1U)
Wall mounting
Energy Efficient
Support
Environment
Operating temperature: 0°C - 40°C
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing
Certification
CCC、FCC、CE、RoHS
L3 Features
VLAN-based routing
IPv4 static routing adding
Supports static ARP adding/deleting
Supports ARP aging time configuration
PoE power supply
NA
Security features
ARP receiving limit
Unknown MAC address discard
DoS attack defense
802.1x security authentication
Radius authentication
VLAN
IEEE 802.1Q VLAN
VLAN Layer-3 interfaces
Supports three port modes: Access, Trunk and Hybrid
