TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink

Komputer & Aksesoris > Komponen Network > Switch Internet & PoE > TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink

TENDA TEF1105P-4-63W 10/100Mbps POE Switch 4 Port 1 Port Uplink

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Hardware
Network standards
IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at
LED Indicator
5* Link/Ack LED indicators
1 * Power LED indicator
Interfaces
4*10/100 Base-TX Ethernet Ports(Data/Power)
1*10/100 Base-TX Ethernet Port(Data)
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity
N/A
Dimension
100.0mmx100.0mmx26.0mm
Level of protection
Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity
1Gbps
Packet forwarding rate
0.74Mpps
Buffer
448K
MAC address table
1K
Jombo frame
N/A
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 58W
Power consumption
/
Input voltage
100-240V AC 50/60Hz
51V /1.25A DC(Power Adapter )
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support
Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certification
FCC、CE、RoHS
Software
Funtions
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other .
Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this funcation can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.

Gambar produk

TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink
