Detail TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink
TENDA TEF1105P-4-63W 10/100Mbps POE Switch 4 Port 1 Port Uplink
"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"
Hardware Network standards IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at LED Indicator 5* Link/Ack LED indicators 1 * Power LED indicator Interfaces 4*10/100 Base-TX Ethernet Ports(Data/Power) 1*10/100 Base-TX Ethernet Port(Data) Transmission media Recommended: CAT5/5e UTP or better Fan quantity N/A Dimension 100.0mmx100.0mmx26.0mm Level of protection Lightning protection for ports: 6kV Lightning protection for power: 6kV ESD: Air discharge: ±10kV Contact discharge: ±8kV Forwarding mode Store-and-forward Switch capacity 1Gbps Packet forwarding rate 0.74Mpps Buffer 448K MAC address table 1K Jombo frame N/A PoE budget Single port: AF: 15.4W, AT: 30W Whole device: 58W Power consumption / Input voltage 100-240V AC 50/60Hz 51V /1.25A DC(Power Adapter ) Mounting Desktop mounting: support Wall mounting: support Rack mounting:non-support Environment Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing Certification FCC、CE、RoHS Software Funtions Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other . Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this funcation can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.
Gambar produk
TENDA TEF1105P-4-63W POE 10/100Mbps Switch 4 Port 1 Port Uplink
