Tenda O9 5Ghz 11AC 23Dbi Gigabit Outdoor CPE

Detail Tenda O9 5Ghz 11AC 23Dbi Gigabit Outdoor CPE

Tenda O9 5Ghz 11AC 23Dbi Gigabit Outdoor CPE
Tenda O9 Gigabit AC Wireless 5Ghz
GARANSI Resmi Tenda Indonesia

Tenda O9/Wireless/5GHz 11ac 23dBi
Gigabit Outdoor CPE
​
Tenda O9, 5GHz 11ac 23dBi gigabit outdoor CPE is designed to PtP and PtMP solutions for privated ISP wireless connectivity, CCTV surveillance and data transmission. It features with 23dBi directional dual polarization antenna to provide an efficient way to pick up and maintain a stable long-distance connectivity . Adopt of auto-bridging technology, two CPE can connect to each other automatically to make it easy to setup.

​Spesifikasi :
Model : O9
Dimension: 391.5*280*223mm
Deployment : Pole Mount
Application Scenarios :PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance
Frequency Range : 5GHz
Compliant Standards : IEEE 802.11a/n/ac
Private TDMA Protocol : TD-MAX
Maximum Wireless Rate : 867Mbps
Interface : 1*10/100/1000Mbps Ethernet Port
Antenna gain : 23dBi
Antenna Beamwidth : Horizontal: 10 Vertical: 10
Reset Button : 1
Power Consumption : 7.5W
Waterproof Level : IP65
LED indicator : PoE/LAN,LED1,LED2,LED3
Power Method : 24V0.5A Passive PoE
Lightning Protection : 6000V
Passive PoE : Passive power over ethenet via PoE/LAN (+4,5pins
-7,8pins ) Voltage range: 21-25V DC
Reception Sensitivity : 11a 6Mbps -96dBm1.5dBm
11n MCS7 HT20 -72dBm1.5dBm
11ac MCS9 HT80 -65dBm1.5dBm
Operating Mode : AP/Station/WISP/P2MP/WDS Repeater/Router
Enable/Disable Wireless Radio : Support
SSID Hidden : Support
Wireless Client isolation : Support
SSID Isolation : Support
Channel Bandwidth : 20/40/80MHz
Channel Shift : Support
Wireless Access Control : Support
Weak Signal Client Limitation : Support
Transmit Power : Adjustable power by 1dBm
WMM Capable : Support
APSD Capable : Support
Wireless Security : 64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transparent Bridge : Support

Gambar produk
