B6 5GHz 11n 300Mbps Basestation
B6 5GHz 11n 300Mbps Basestation is designed for PtP and PtMP solutions for rural wireless connectivity and CCTV surveillance.Features with two RP- SMA enable it to pair with dish antenna or sector antenna to establish PtP backhaul connection and P2MP link.

Product Information
Model
B6
Dimension
190*84*37mm
Deployment
Pole Mount
Application Scenarios
PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance
Hardware
Frequency Range
5GHz
Compliant Standards
IEEE 802.11a/n
Maximum Wireless Rate
300Mbps
Interfaces
1*10/100Mbps Ethernet Port
Antenna
2*RP-SMA Connector
Antennas Gain
/
Antenna Beamwidth
/
GND
1*GND
Reset Button
1*Reset Button
Power Consumption
8.5W
Waterproof Level
IP65
LED Indicator
Power, PoE/LAN,LED1,LED2,LED3
Power Method
24V0.5A Passive PoE
Lightning Protection
6000V
Passive PoE
Passive power over ethenet via PoE/LAN ( ✚4,5pins
-7,8pins) Voltage range: 21-25V DC
Reception Sensitivity
11a 6Mbps -96dBm±1.5dBm
11n MCS0: -96±1.5dBm
11n MCS7: -72±1.5dBm
Software
TDMA
Support
Operating mode
AP/Station/WISP/P2MP/WDS Repeater/Router
Enable/Disable Wireless Radio
Support
SSID Hidden
Support
Wireless Client isolation
Support
SSID Isolation
Support
Channel Bandwidth
10/20/30/40MHz
Channel Shift
Support
Wireless Access Control
Support
Weak Signal Client Limitation
Support
Transmission Power
Adjustable power by 1dBm
WMM Capable
Support
APSD Capable
Support
Wireless Security
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transparent Bridge
Support
VLAN Tagging for SSID
Support
DHCP Server
Support
VPN Pass-Through
PPTP,L2TP
Remote Web access
Support
Schedule Reboot
Support
Page Timeout
Support
Ping Watchdog
Support
Dyndns
noip, dyndns.org
Network Diagnoses
Ping, Traceroute, Signal Scan
Time&Date Setting
Support
Firmware upgrade
Support
