SYNOLOGY DS220J 2 HardDisk Bay Diskstation

Detail SYNOLOGY DS220J 2 HardDisk Bay Diskstation

Specification:
Hardware
CPU
CPU Model Realtek RTD1296
CPU Quantity 1
CPU Architecture 64-bit
CPU Frequency 4-core 1.4 GHz
Hardware Encryption Engine
Memory
System Memory 512 MB DDR4 non-ECC
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)


3.5" SATA HDD
2.5" SATA HDD (with optional 2.5" Disk Holder)
2.5" SATA SSD (with optional 2.5" Disk Holder)

Maximum Single Volume Size* 108 TB
Hot Swappable Drive -
Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port 1
USB 3.2 Gen 1 Port* 2
Notes The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System
Internal Drives

EXT4

External Drives

EXT4
EXT3
FAT
NTFS
HFS+
exFAT*

Appearance
Size (Height x Width x Depth) 165 mm x 100 mm x 225.5 mm
Weight 0.88 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode

Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode

Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 18.2 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 60 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 12.46 W (Access)
5.06 W (HDD Hibernation)
British Thermal Unit 45.52 BTU/hr (Access)
17.27 BTU/hr (HDD Hibernation)
Notes

Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification


EAC
CCC
KC
FCC
CE
BSMI
VCCI
RCM
Warranty
2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
VisualStation: VS960HD/VS360HD
Surveillance Device License Pack
Disk Holder: Type C
