Sunhokey Prusa i4 Voltage Convertor DC-DC Step Down Module Efisien

Detail Sunhokey Prusa i4 Voltage Convertor DC-DC Step Down Module Efisien

3D Zaiku Indonesia
Sunhokey Prusa i4 Voltage Convertor DC-DC Step Down Module Efisien


Specification:
Input voltage: 16-40V (Rated 24V is the Best)
Output voltage: 1.0-12V
Output Current: 6A
No-load current: 10.2mA (24V switch 12V) 7.7mA (24V turn 5V)
Start with a load current rating 6A, the largest 7A.
Type of protection: undervoltage shutdown, overcurrent shutdown
Even a long time short circuit will not damage (short circuit start)!
Please try to avoid frequent short-circuit when in normal output, in order to avoid shocks to burn mos tube
Dimensions: length (68mm) * width (43mm) * height (22mm)

Efficiency Test:
24V turn 5V / 6A:
Efficiency = (5.00 * 6.00) / (24 * 1.34) * 100% = 93.3%
