Detail STRW6754 STR W6754 STRW6754A 6754

STRW6754 STRW6754A STR W6754A W6754 BC56

Description:
The STR-W6754 is a quasi-resonant topology IC designed for SMPS applications. It shows lower EMI noise characteristics than conventional PWM solutions, especially at greater than 2 MHz. It also provides a soft-switching mode to turn on the internal MOSFET at close to zero voltage (VDS bottom point) by use of the resonant characteristic of primary inductance and a resonant capacitor.

Features and Benefits:
Quasi-resonant topology IC
---Low EMI noise and soft switching
Bottom-skip mode
---Improved system efficiency over the entire output load by avoiding increase of switching frequency
Auto-Standby mode
---Lowers input power at very light utput load condition
Avalanche-guaranteed MOSFET
---Improves system-level reliability and does not require VDSS derating
650 V / 0.96
Various protections
---Improved system-level reliability

Gambar produk
