Detail Step down LM 2596 HV mobile phone charging board (8129)
Step down LM 2596 HV mobile phone charging board (8129)Module parameters:
Input voltage: 7-56V limit 56V, try to leave some margin
Output Voltage: Fixed 5V
Output current: maximum 3A, best within 2.5A for long-term operation
Output power: maximum 15W (output current calculation formula: 15/output voltage = output current)
Conversion efficiency: up to 92% (the higher the output voltage, the higher the efficiency)
The static power consumption is only about 6mA.
Operating temperature: Industrial grade (-40°C to +85°C)
Module nature: non-isolated step-down module
