Capacity :128GB, 256GB, 512GB, 1TB Form Factor :M.2 2280 Port : PCIe Gen 3.0 x 4 Memory Component : 3D NAND
Sequential Read : Up to 1250 MB/s (128GB) Up to 2000 MB/s (256GB) Up to 2000 MB/s (512GB) Up to 2000 MB/s (1TB)
Sequential Write : Up to 650MB/s (128GB) Up to 1050 MB/s (256GB) Up to 1450 MB/s (512GB) Up to 1600 MB/s (1TB)
MTBF : 1,500,000 hours Operating Temperature : 0°C to +70°C (+32°F to +158°F) Storage Temperature : –40°C to +85°C (–40°F to +185°F) Operating Humidity : 5%–95% (non-condensing) Vibration Resistance : 10–200 Hz, 0.5 G Shock Resistance : 1500 G/0.5 ms (half sine wave)
1. Capacity calculation: 1 GB = 1 billion bytes (IDEMA). Actual available capacity might be reduced (due to formatting, partition, operating system applications, or other necessary usage). 2. The dimensions are after installing cooling plate. 3. System configuration of performance test: Intel Z390 Chipset, Intel Core i9-9900KF@3.6GHz, 16GB DDR4,; operating system-Windows 10 x64; testing tool-CrystalDiskMark 6.0.0. 4. Warranty period or maximum write amount (TBW), whichever comes first. 5. High performance SLC cache has been enabled. *Above data based on internal testing of Dahua Memory Laboratory
