Splicer Tumtac 13MMT S1 Ready

Detail Splicer Tumtac 13MMT S1 Ready

Specification for Fusion Splicer Tumtec 13MT 13MMT Model 13MMT Number of Fiber Single Appicable Fibers SM(ITU-T G. 652&G.657),MM(ITU-T G.651),DS(ITU-T G.653),NZDS(ITU-T G655) Compatible Fiber/Cable 0.25-3.0mm/Indoor Cable Cleaved Length Coating Diameter: 0.125-1mm/Cleave length:5-16mm Splicing Mode Multiple Splicing Modes Typical Splice Loss 0.01-0.05db Return Loss 60db Lighting 3 powerful white LED and illuminated keypads Splicing Time 6-8 seconds Estimated Splice Loss Available Protection Sleeve Length 20-60mm Heating Mode Multi Heating Modes Heating Time Typical Heating Time: 15s Results Storage 2000 records Tension Test 1.5-2.0N Operating Condition Operating altitude 0-5000m above sea level, 0-95% relative humiditym-10~50 max wind 15m/s Storage Condition 0~95% relative humidity, -40~80 Display 90bi-directional view,4.3 color high resolution display with touch screen Fiber View & Magnification X,Y,XY,X/Y:380Magnification Power Supply AC Input 100-240V,DC Input 12-15V No. of Splice/Heating with Battery 4800mAh battery capacity, typical above 200 times(splice+heat) Operating Methods Button/Touch Screen Automatic Calibration Automatic ARC calibration by air pressure and temperature Electrode Life 3500 ARCS, can be extended by using an electrode grinder Terminal USD 2.0/Phone Jack 140W*165L*160Hmm (including rubber Bumper) Dimension 140W*165L*148Hmm (including rubber Bumper) 130W*165L*138Hmm (excluding rubber Bumper) Kelengkapan Charger Batere 5200mAh Striper Cleaver Tang dropcore Soc holder Elektroda Botol alkohol Box

Gambar produk
