Detail SPEAKER TOA ZS1030 TOA ZS 1030 ZS1030
Inclosure 2-way bass-reflex type
Rated Input 30 W
Rated Impedance 8
100 V line: 330 ( 30 W) , 500 ( 20 W) , 670 ( 15 W) , 1 k ( 10 W) , 2 k ( 5 W)
70 V line: 170 ( 30 W) , 250 ( 20 W) , 330 ( 15 W) , 500 ( 10 W) , 1 k ( 5 W)
Sound Pressure Level 90 dB ( 1 W, 1 m)
Frequency Response 80 Hz - 20 kHz
Speaker Component 12 cm cone-type + dome-type
Speaker Cord 2-core cabtyre cord with diameter of 6 mm
Operating Temperature -10 to + 50
Water Protection IPX4 ( can be installed vertically or horizontally.* )
Finish Enclosure: ABS resin, black ( RAL9011 GRAPHITE BLACK) , paint
Net: Surface treated steel plate, black ( RAL9011 GRAPHITE BLACK) , powder coating
Bracket: Surface treated steel plate, black equivalent to RAL9011 GRAPHITE BLACK,
powder coating
Dimension 196 ( W) 290 ( H) 150 ( D) mm ( unit only)
Weight 2.5 kg ( unit only)
Accessory Bracket 1, Bracket mounting screw 2, Bracket mounting washer 2
Option Applicable bracket: WCB-12, TMB-1, SP-410
