SPEAKER RCF L10 750YK 10 inch GRADE A

Detail SPEAKER RCF L10 750YK 10 inch GRADE A

TUNAS JAYA

Deskripsi SPEAKER RCF L10 750YK ( 10 inch ) GRADE A
Speaker komponent RCF L10 750YK Woofer 10 inch Grade A

The L10-750YK is a professional mid-bass woofer featuring very high uotput and dynamics.

The mobile equipment, used a 3" coil, fiberglass former and copper wire winding, has enable considerable improvement in transient peak response and has allowed good extension on mid-high frequencies.
A specially designed M-roll surround guarantee a very low midrange distortion and perfect damping of the spurious resonances.


Features
3-inch, fiberglass inside/outside copper voice coil
700W continuous program power handling
100 dB Sensitivity
70 Hz 3 kHz Frequency range
Shaped M-roll damped surround

Applications
The L10-750YK is primary designed to be horn loaded in medium and long throw system.
When mounted in compact size bass reflex enclousures, the good combination of short voice coil, very low mass and suspensions control makes the L10-750YK a very good choise for high power, 2 way, satellite applications.


General Specifications
Nominal Diameter : 250 / 10 mm/inch
Rated Impedance : 8
Program Power : 700 W AES
Power handling capacity : 350 W AES
Sensitivity: 100 dB
Frequency Range : 70 Hz 3000 Hz
ffective Piston Diameter : 210 / 8.3 mm/inch
Max Excursion Before Damage peak to peak : 40 / 1.6 mm/inch
Minimum Impedance : 6.7
Voice Coil Diameter : 76 / 3 mm/inch
Voice Coil Material : Copper
Voice Coil Winding Depth : 9 / 0.35 mm/inch
Number of layers : 2
Kind of layer : inside / outside
Top Plate Thickness : 9 / 0.35 mm/inch
Cone Material : No pressed pulp
Cone Design : Curved
Surround Material : Polycotton
Surround Design : M - roll

Gambar produk
