Detail Speaker Management DriveRack PA DBX PA

Specifications

Input (2) line inputs. (1) RTA Mic input
Input Connectors (2) Female XLR line inputs. XLR RTA Mic input
Input Type Electronically balanced/RF filtered
Input Impedance >40k ohm
Max Input >+20dBu
CMRR > 45dB
Mic Preamp Phantom Power +15VDC (RTA)
Mic Preamp Equivalent Input Noise (EIN) 107 dB weighted
Type IV Dynamic Range 123 dB with transient material, A-weighted, 22kHz BW; 121 dB with transient material, unweighted, 22kHz BW; 115 dB typical with program material, A-weighted, 22kHz BW
Sample Rate 48kHz
D/A Dynamic Range 112 dB A-weighted, 110dB unweighted
Dynamic Range >110 dB A-weighted, >107dB unweighted
THD+Noise 0.004% typical at +4dBu, 1kHz, 0dB input gain
Frequency Response 20Hz 20kHz, +/- 0.5dB
Interchannel Crosstalk < -110 dB, -120dB typical (input-to-output: < -100 dB)
Operating Voltage 100-120VAC 50/60 Hz EU: 220-240 VAC 50/60 Hz
Power Consumption 25 W

Gambar produk

Speaker Management DriveRack PA DBX PA
