SPEAKER CELLING BOSCH LBC 3099 ORIGINAL CEILING BOSCH LBC3099 24 WATT

Detail SPEAKER CELLING BOSCH LBC 3099 ORIGINAL CEILING BOSCH LBC3099 24 WATT

BARANG 100% ORIGINAL BOSCH PRODUCT

The LBC 3099/41 Ceiling Speaker 8" 24w Dual Cone Ceiling Speaker is our most popular 100v ceiling speaker
It's the best sounding speaker across all the brands that we sell.
Off axis responce is excellent with a wide dispersion ( 160 degrees @ 1khz )
handy when trying to minimise the number of units required to cover a large area.

Features
Excellent speech and music reproduction
High sound pressure level
Ideal for high-ceiling applications
Flush mounted in ceilings

The LBC 3099/41 is a flush-mounting ceiling loudspeaker
for applications where extra power is required, such as
rooms with high ceilings. It delivers a high sound pressure
level and has a wide frequency range to ensure excellent
speech intelligibility and good quality music reproduction.
It is used in applications like shops, department stores,
schools, offices, sports halls, hotels and restaurants.

The LBC 3099/41 has a single-piece, 24 W, dual-cone
loudspeaker. A 100 V matching transformer is mounted on
the back of the frame. An attractive metal grille is
integrated with the front, and finished in an unobtrusive
white color (RAL 9010).

Clamp mounting
Simple power setting
Unobtrusive white metal grille
Ball-proof
Complies with international installation and safety regulations
BS 58398 and EN 60849 compliant

Technical Specifications

Electrical*
Maximum power 36 W
Rated power (PHC) 24 / 12 / 6 W
Sound pressure level
at 24 W / 1 W (1 kHz, 1 m)
106 dB / 92 dB (SPL)
Sound pressure level
at 24 W / 1 W (4 kHz, 1 m)
107 dB / 93 dB (SPL)
Effective frequency range
(-10 dB)
60 Hz to 18 kHz
Opening angle
at 1 kHz/4 kHz (-6 dB)
160 / 60
Rated voltage 100 V
Rated impedance 417 ohm
Connector 3-pole sc
