SMSL M300 SE M300SE M 300 SE S.M.S.L CS43131 MQA Audio DAC Amplifier

Detail SMSL M300 SE M300SE M 300 SE S.M.S.L CS43131 MQA Audio DAC Amplifier

Note :
Garansi Resmi 1 Tahun

SMSL M300 SE
A new series of exterior design with tempered glass panel, both high-end feeling and durable!
Cirrus Logic's latest audio decoder chip CS43131, with carefully designed circuitry, achieves an unprecedented 0.00013% (-117dB) distortion performance!
The new third generation XMOS XU-316, PCM support up to 32bit /768kHz, DSD support up to DSD512.
USB support MQA full decoding;
Bluetooth 5.0 digital audio input, external antenna, farther transmission distance.
The clock system uses independent ultra-low clock jitter, ultra-low phase noise for the audio clock.
Built-in high-efficiency power supply chip for the decoder to provide sufficient energy, and the use of multiple groups of low-noise LDO power supply.
The use of a large number of audio-specific audiophile resistors and capacitors.
The use of 1.29 "OLED display.
Fully balanced design, and has a true balanced output.
With 6.35mm, 4.4mm balanced headphone output.
Equipped with full-featured remote control and preamp function.
All aluminum CNC precision machining chassis to effectively reduce the thousand disturbances.

Specifications:-
Inputs:USB / Optical / Coaxial / Bluetooth
Output Level:RCA 2.0Vrms XLR 4.0Vrms
THD+N(UN-WTD):0.00013% (-117dB)
Dynamic range (UN-WTD):RCA 120dB XLR 132dB
SNR (UN-WTD):131dB
Bluetooth:BT 5.0 ( support SBC)
USB transmission:Asynchronous
USB compatibility:Windows 7 / 8 / 8.1 / 10 Mac OS X10.6 or Later / Linux
Bit depth: USB:1bit ~ 32bit
Optical/coaxial:16bit ~ 24bit
Sampling rate: USB:44.1 ~ 768kHz DSD64, DSD128, DSD256, DSD512
Optical/coaxial:32 ~ 192kHz
Power Consumption:3W
Standby power:＜0.1W
Size:70x73x165mm (WxHxD)
Weight:0.54Kg
