The NX-1700 supports 4 Mbps of WAN bandwidth and 8,000 flows. The NX-1700’s quiet operations and flexible mounting options make it ideal platform for small and remote office environments.
Capacity WAN Bandwidth Capacity (all features + encryption) 4 Mbps Simultaneous Connections 8,000 Resiliency Disk Drives Single Power Supplies Single Network 1+1 and N+1 with VRRP or WCCP RAM ECC memory MTBF 62,788 hours (7.2 years) Security Disk Encryption 128-bit AES Network Encryption IPsec (256-bit AES) Connectivity LAN/WAN Ethernet 4 x 10/100/1000 LAN/WAN (2 LAN/ 2 WAN) as per IEEE 802.3i, 802.3u, 802.3ab, 802.1Q Management 2 x 10/100/1000; Console port Deployment In-line Bridge Mode In-line between L2 switch and WAN router with fail-to-wire in case of failure Out-of-Path (Router) Mode Attached to WAN router out-of-path with PBR re-direction, WCCP, and VRRP Power Requirement 100-240VAC / 47-63Hz / 46W / 157 BTU or less
