SCANNER PERIKSA NILAI LJK PLUSTEK SmartOffice PS388U Automatic Document Feeder (ADF)

Detail SCANNER PERIKSA NILAI LJK PLUSTEK SmartOffice PS388U Automatic Document Feeder (ADF)

Spesifikasi Hardware

Type Automatic Document Feeder (ADF)

Image Sensor CIS x 2 (duplex)

Optical Resolution 600 dpi

Hardware Resolution 600 x 600 dpi




ADF Capacity

* 1. 50 sheets (A4/Letter, 70 g/㎡ or 18 lb.), Max. thickness under 5mm (0.2″).
* 2. 20 sheets (Business Cards)
* 3. Plastic Card, Max. thickness under 1.2 mm.

Note: Maximum ADF capacity varies, depending upon paper weight.




Scanning Speed ( ADF )

* 30 ppm/ 60 ipm (Grayscale mode, 200 & 300 dpi, A4 Portrait)
* 30 ppm/ 60 ipm (B&W mode, 200 & 300 dpi, A4 Portrait)
* 30 ppm/ 60 ipm (Color mode, 200 & 300 dpi, A4 Portrait)

Note: Results may vary depending upon your scanning application, computer
processor and system memory.




Scanning Area (W x L)

* Max: 216 x 1270 mm (8.5” x 50”)
* Min: 13.2 x 13.2 mm (0.52” x 0.52”)

Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4), Legal




Acceptable Paper Sizes (W x L)

* Max: 220 x 1300 mm (8.66” x 51”)
* Min: 50.8 x 50.8 mm (2” x 2”)




Acceptable Paper Weight (Thickness) 50 to 105 g/㎡ (14 to 28 Lbs)

Daily Duty Scan ( Sheets ) 4000

Roller Lifetime (Scans) 300.000

Pad Lifetime (Scans) 50.000

Action Button Scan, PDF, OCR, File, E-Mail, Copy, BCR, FTP. All Customizable.

Power Supply 24Vdc/0.75 A

Interface USB 2.0

Net Weight 1.66 Kgs (3.66 Lbs)

Dimensions (W x D x H) 263 x 127.5 x 148 mm (10.36” x 5.02” x 5.83”)

Protocol TWAIN Compliant




Operating System

Windows 7-10

Mac Os 10.8-10.13




Hardware Requirements

Pentium IV 2.4 GHz processor (Pentium IV 3.0 GHz processor recommended)

DVD-ROM Driver

One available USB Port (USB 2.0 recommended)

1GB RAM or higher recommended

2GB free HDD space (3GB or larger recommended)

High Color graphic card (VGA or higher)




Spesifikasi Berat Produk

Berat Bersih 1,66 Kg

Berat Kotor 5 Kg

Dimensi Produk (P) 26,3 x (L) 12,7 x (T) 14,8 cm

Dimensi Kardus Luar (P) 37 x (L) 25 x (T) 30 cm




**Note :

Untuk Pengiriman di Luar Daerah, kami menyarankan untuk menggunakan Packing Kayu
Tambahan untuk Meminimalisir Kerusakan dalam Pengiriman Jarak Jauh.

Harga Belum Termasuk Biaya Pengiriman. Mohon tanyakan kepada kami terlebih
dahulu / silahkan Pilih kurir yang anda butuhkan.

==========================================================

Gambar produk
