SCANNER DOKUMEN PLUSTEK SmartOffice PN2040 Automatic Document Feeder (ADF) & Flatbed

Detail SCANNER DOKUMEN PLUSTEK SmartOffice PN2040 Automatic Document Feeder (ADF) & Flatbed

SCANNER DOKUMEN PLUSTEK SmartOffice PN2040 Automatic Document Feeder (ADF) &
Flatbed





Spesifikasi Hardware

Type; Automatic Document Feeder (ADF) & Flatbed

Image Sensor; CIS x 2

Optical Resolution; 600 dpi




Hardware Resolution

* Flatbed: 600 x 600 dpi
* ADF: 600 x 600 dpi




ADF Capacity

* 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2″).

Note: Maximum ADF capacity varies, depending upon paper weight.




Scanning Speed ( ADF )

* 9 ppm/ 10 ipm (Color mode, 200 dpi, A4 Portrait)
* 20 ppm/ 40 ipm (Grayscale mode, 200 dpi, A4 Portrait)
* 20 ppm/ 40 ipm (B&W mode, 200 dpi, A4 Portrait)

Note: Results may vary depending upon your scanning application, computer
processor and system memory.




Scanning Area (W x L)

Flatbed:

* Max. 216 x 297 mm (8.5″ x 11.69″)
* Min. 12.7 x 12.7 mm (0.5″ x 0.5″)
* Scan: Kartu Nama, A5, Kuarto, Letter & A4

ADF:

* Max. 216 x 356 mm (8.5″ x 14″)
* Min. 13.2 x 13.2 mm (0.52″ x 0.52″)
* Scan: Kartu Nama, A5, Kuarto, Letter, A4, Folio (F4) & Legal




Acceptable Paper Sizes (W x L)

Flatbed:

* Max. 216 x 297 mm (8.5” x 11.69”)
* Min. 12.7 x 12.7 mm (0.5” x 0.5”)

ADF:

* Max. 220 x 356 mm (8.66” x 14”)
* Min. 90 x 50.8 mm (3.55” x 2”)

Acceptable Paper Weight (Thickness); 50 to 120 g/㎡ (14 to 32 Lbs)

Daily Duty Scan ( Sheets ) ;    1.400

Roller Lifetime (Scans); 100.000

Pad Lifetime (Scans); 25.000

Action Button; Scan, PDF, Custom

Power Supply; 24 Vdc/ 0.75 A

Interface;

* USB 2.0 x 1,
* RJ45 LAN (network connection) x 1

Net Weight; 3.78 Kgs (8.33 Lbs)

Dimensions (W x D x H); 418 x 326 x 101 mm (16.45″ x 12.83″ x 4″)

Protocol; TWAIN Compliant

OS; Windows XP / Vista / 7 / 8 / 10 / 11




Hardware Requirements

* Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended)
* CD-ROM Driver
* One available USB Port (USB 2.0 recommended)
* 1GB RAM or higher recommended
* 800 MB free HDD space (1 GB or larger recommended)

Spesifikasi Berat Produk

* Berat Bersih 3,78 Kg
* Berat Kotor 9 Kg
* Dimensi Produk (P) 41,8 x (L) 32,6 x (T) 10,1 cm
* Dimensi Kardus Luar (P) 59 x (L) 55 x (T) 29 cm

**Note :

Untuk Pengiriman di Luar Daerah, kami menyarankan untuk menggunakan Packing Kayu
Tambahan untuk Meminimalisir Kerusakan dalam Pengiriman Jarak Jauh.
