Boost Clock: Up to 2755 MHz Game Clock: Up to 2355 MHz
Stream Processors 2048 Compute Units 32 CU Infinity Cache 32MB Ray Accelerators 32 Memory Size/Bus 8GB/128 bit GDDR6 Memory Clock 18 Gbps Effective Displays Maximum 4 Displays Resolution
HDMI™: 7680×4320 DisplayPort 1.4: 7680×4320
Interface
PCI-Express 4.0 x8 Output
1x HDMI 3x DisplayPort
BIOS Support
UEFI
Game Index
1080P Ultimate Sapphire Features
Fuse Protection Dual-X Cooling Technology Intelligent Fan Control Precision Fan Control Metal Backplate Two-Ball Bearing Fans Optimized Composite Heatpipe TriXX Supported TriXX Boost
AMD Features
AMD RDNA 3 Architecture DirectX 12 Ultimate AMD Smart Access Memory AMD Infinity Cache PCI Express 4.0 Support AMD FreeSync™ Technology DisplayPort 1.4 with DSC HDMI Video Streaming up to 8K AMD Radeon VR Ready Premium AMD Radeon Image Sharpening AMD Radeon Anti-Lag AMD Software: Adrenalin Edition™ Technology Game Driver Optimizations
Cooling
2 Fans Form Factor 2 slot, ATX Dimension: 240(L)X 107.1(W)X 44.07 (H)mm Power Consumption
185W Total Board Power OS
Linux®, Windows® 10, and Windows 11. 64-bit operating system required System Requirement
Minimum 550 Watt Power Supply 1 x 8-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
