Capacity 500GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor M.2 (2280)
Interface PCIe Gen 3.0 x4, NVMe 1.4
Dimension (Pack: WxHxD) 80.15 x 22.15 x 2.38 (mm)
Weight Max 8.0 g Weight
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung Pablo Controller
Cache Memory HMB(Host Memory Buffer)
Special Feature TRIM Support Supported
S.M.A.R.T Support Supported
GC (Garbage Collection) Auto Garbage Collection Algorithm
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support Not supported
Device Sleep Mode Support Yes
Performance Sequential Read Up to 3,100 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Up to 2,600 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32) Up to 400,000 IOPS* Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) Up to 470,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1) Up to 17,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1) Up to 54,000 IOPS * Performance may vary based on system hardware & configuration
