Samsung 870 EVO 500GB 2.5" SATA SSD [GS]

Detail Samsung 870 EVO 500GB 2.5" SATA SSD [GS]

SPECIFICATIONS

Form Factor
2.5 inch
Capacity
500GB
Sequential Read Speed
Up to 560 MB/s
Sequential Write Speed
Up to 530 MB/s
Model Code (Capacity)1)
MZ-77E500 (500GB)
General Feature
Application
Client PCs
FORM FACTOR
2.5 inch
INTERFACE
SATA 6 Gb/s Interface,
compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
DIMENSION (WxHxD)
100 X 69.85 X 6.8 (mm)
WEIGHT
500GB: Apporx. 45.0g
STORAGE MEMORY
Samsung V-NAND 3bit MLC
CONTROLLER
Samsung MKX Controller
CACHE MEMORY
Samsung 512 MB Low Power DDR4 SDRAM (500GB)
Special Feature
TRIM Support
Yes
S.M.A.R.T Support
Yes
GC (GARBAGE COLLECTION)
Auto Garbage Collection Algorithm
ENCRYPTION SUPPORT
AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)
WWN SUPPORT
World Wide Name supported
DEVICE SLEEP MODE SUPPORT
Yes
Performance
SEQUENTIAL READ
Up to 560 MB/s
SEQUENTIAL WRITE
Up to 530 MB/s
RANDOM READ (4KB, QD32)
Up to 98,000 IOPS
RANDOM WRITE (4KB, QD32)
Up to 88,000 IOPS
RANDOM READ (4KB, QD1)
Up to 13,000 IOPS
RANDOM WRITE (4KB, QD1)
Up to 36,000 IOPS
Environment
AVERAGE POWER CONSUMPTION
(System Level)
500GB: Average: 2.2 W Maximum: 3.5 W (Burst mode)
POWER CONSUMPTION (IDLE)
500GB: Max. 30 mW
ALLOWABLE VOLTAGE
5V ± 5% Allowable voltage
RELIABILITY (MTBF)
1.5 Million Hours Reliability
OPERATING TEMPERATURE
0 - 70 ℃
Shock
1,500 G & 0.5 ms (Half sine)
Accessories
INSTALLATION KIT
N/A
