Detail Saklar Switch Bulat 3 pin (on-off) Non Lampu Indikator

Specification:
Material: Plastic, Electric Component
Dimensi diameter 15mm tinggi 17mm
Color: Black
Poles: SPST (Single Pole Single Throw)
Pin: 2 ON-OFF
Rated at: 3A 250V ; 6A 125V
Contact Resistance: 35mΩ max
Insulation Resistance: 100MΩ at 500VDC
Dielectric Strength: 1500V AC for 1 minute
Operating Temperature: -25- +85 Celsius
Electrical Life: 10000 Cycles
