Ruijie RG-EAP602 | AC1200 Dual Band Gigabit Outdoor AP

Detail Ruijie RG-EAP602 | AC1200 Dual Band Gigabit Outdoor AP

Ruijie RG-EAP602|AC1200 Dual Band Gigabit Outdoor AP

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Ruijie Reyee Series RG-EAP602 is a high-power outdoor omnidirectional dual-band wireless access point supporting 802.11b/g/n/ac, which is designed for villages, villas, parks, scenic spots, plazas, etc. With concurrent 2.4GHz and 5GHz, the AP supports dual-band dual-stream MIMO technology, which can provide 300Mbps at 2.4GHz, 867Mbps at 5GHz and up to 1167Mbps per AP. The built-in omnidirectional high-gain antennas provide excellent coverage for the users.

Highlight：

• 802.11ac Wave2 technology
• 300m coverage radius
• Auto-provisioning via Self-Organizing Network：Supports Ruijie’s self-developed smart networking feature, which breaks through the product limitations and realizes auto-discovery, auto-networking and auto-configuration between routers, switches, and wireless APs without the need for controllers or Internet access;
• Lifetime free Ruijie Cloud management: Remote fault alarm, one-click optimizing and maintenance on Ruijie Cloud App;
• Stable wireless service under harsh environment： Surge Protection 6KV | IP Rating IP68 | Operating temperature: -30°C～65°C
• Industrial Design

Model

RG-EAP602

Radio

2.4GHz & 5GHz dual-band dual-stream

Protocol

2.4GHz: 802.11 b/g/n；5GHz: 802.11a/b/g/n/ac

Spatial Streams

2.4GHz: 2 Spatial Streams, 2x2 MIMO
5GHz: 2 Spatial Streams, 2x2 MIMO

Max Throughput

2.4GHz: 300Mbps

5GHz: 867Mbps

Up to 1167Mbps per AP

Transmit Power

≤500mw（27dBm，RF transmit power only）

Dimensions

200mm*220mm*166mm (excluding mounting kits)

Weight

1kg (excluding mounting kits)

Service Ports

2 10/100/1000Mbps Ethernet ports（one of which supports 802.3af/at PoE）

1 reset button

Reset

1 DC 12V power socket

LED Indicators

Wi-Fi indicator, warning indicator, LAN1 connection indicator, LAN2 connection indicator

Power Supply

802.3af / 802.3at

DC 12V 1.5A

Built-in Antennas

Built-in omnidirectional antennas (basic gain 3dBi)

Power Consumption

＜12.95W

Coverage Radius
