Ruijie RG-AP720 L Wireless Access Point AP 720L Include Adaptor POE Orignal RUijie

Detail Ruijie RG-AP720 L Wireless Access Point AP 720L Include Adaptor POE Orignal RUijie

RUijie Access Point Ceiling Indoor RG-AP720-L MU-MIMO Include Adaptor PoE Original RUijie

GARANSI RESMI RUijie Indonesia

The Ruijie AP720-L is a high performance 802.11ac Wave 2 access point with 2x2 MU-MIMO and concurrent Dual-band design, data rate of up to 1.167Gbps.

Spesifikasi :
Model Ruijie AP720-L
Target Deployment Retail Chain Store, Small & Medium-sized Business Office, Boutique Hotel
Type Indoor Ceiling/Wall-mounting
Basic Spec Radio Concurrent Dual-band
Protocol 802.11a/b/g/n/ac
Wave2
Operating Bands 802.11b/g/n: 2.4GHz to 2.483GHz

802.11a/n/ac: 5.150GHz to 5.350GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.850GHz (vary depending on countries)
Antenna Built-in Omni-directional Antenna
Antenna Gain 2.4G: 3dBi
5G: 3dBi
Max Throughput Maximum throughput of 2.4G: 300Mbps
Maximum throughput of 5G: 867Mbps
Maximum throughput per AP: 1167Mbps
Modulation OFDM：BPSK@6/9Mbps，QPSK@12/18Mbps，16-QAM@24Mbps，64-QAM@48/54Mbps
DSSS：DBPSK@1Mbps，DQPSK@2Mbps，and CCK@5.5/11Mbps
MIMO-OFDM：BPSK, QPSK, 16QAM, 64QAM, 256QAM
Receiver Sensitivity 11b：-96dBm（1Mbps），-93dBm（5Mbps），-89dBm（11Mbps）
11a/g：-91dBm（6Mbps），-85dBm（24Mbps），-80dBm（36Mbps），-74dBm（54Mbps）
11n：-90dBm（MCS0），-70dBm（MCS7），-89dBm（MCS8），-68dBm（MCS15）
11ac HT20：-88dBm（MCS0）, -63dBm（MCS9）
11ac HT40：-85dBm（MCS0）, -60dBm（MCS9）
11ac HT80：-82dBm（MCS0）, -57dBm（MCS9）
Spatial Streams 2x2
Maximum Transmit Power 100mW
IP Rating IP41
Ports 1 10/100/1000BASE-T Ethernet uplink
Port LAN1 supports PoE
1 Console Port
Power Power Supply
PoE (802.3af）
Power Consumption <12.95W
WLAN Maximum clients per AP 256
BSSID capacity 32
Remote Intelligent Perception Technology (RIPT) Support
Intelligent load balancing based
#RUIJIE
