REGULATOR DC to DC 12V to 5V 3A Converter Step-down Buck Module

Detail REGULATOR DC to DC 12V to 5V 3A Converter Step-down Buck Module

ready merk fulree

Features:
Full seal design, shock proof, dust proof and waterproof.
Aluminum alloy shell features good heat dissipation.
Compact design, high efficiency, easy installation and use.
Copper cord ensure high and stable conductivity.
With overload,over-current, over temperature, short circuit protections.
Wildly used for the carcorder, car navigation, car audio, car radio, bus LED display, taxi LED screens etc.

Descriptions:
Input: 8V-22V
Output voltage: 3V/3.3V/3.7V/4.2V/5V/6V7.5V/9V Selectable
Output Current(max): 3A(2A when it is 9V)
Output Power: 9-18W
Conversion efficiency: up to 96%
Soft-start time: 500mS
Output ripple:50mV (MAX) 20M-bandwidth
Dynamic response speed: 5% 200uS

Specifications:
Material: aluminum
Size: 35x25x21mm
Color: silver & black

Package included:
1 x Step-Down Voltage Converter
