Refrigerated Air Dryer FK-8.5 ACS - Araki

Detail Refrigerated Air Dryer FK-8.5 ACS - Araki

Setiap hari buka termasuk hari minggu/libur, silahkan di pesan barangnya dan kami akan mengirimkan barang pesanan anda secepat mungkin.

Mohon Tanyakan Stock terlebih dahulu sebelum Melakukan Order !!
Untuk menghindari Penolakan Order, Mohon Tanyakan Stock terlebih dahulu sebelum Melakukan Order !!

Spesifikasi Produk
ARAKI REFRIGERATED AIR DRYER FK-8.5ACS
Model : FK-8.5ACS
Capacity : 8500L/min (8.5Nm3/min)
Pressure Range : 0.6 - 1.6 Mpa
Power Supply : 1 Phase 220V 50Hz
Compressor Power : 2.8 HP
Fan Power : 2x135 Watt
Air Interface : G2”
Dewpoint : 2°C - 10°C
Ambient Temp Range : 5°C - 50°C
Air Inlet Temperature Range : 20°C - 60°C
Nett Weight (Kgs) : 160
Dimension (L x W x H) mm : 770x600x960
Warranty : 1 Years for Compressor

Features :
• Excellent Properties Refrigerated Air Dryers of ARAKI Series
• Plate fin type heat exchanger with three-in-one design : Heat exchanger, evaporator & Gas-liquid Separator be combine together
• The temperature of the dew point is steady
• Energy saving of 20% for compressor power
• Bigger precoler & backheating design to reduce the 15% load for the evaporator to reduce the cost

Gambar produk
