Redmi Router AC2100 Gigabit 2033Mbps Dual Band

Detail Redmi Router AC2100 Gigabit 2033Mbps Dual Band

Redmi Router AC2100
Model : RM2100

Specifications:

CPU : MT7621A MIPS Dual core 880MHz
ROM : 128MB
Memory : 128MB
Wireless rate : 2.4G Wi-Fi: 2*2 (IEEE 802.11n, 300Mbps)
5G Wi-Fi: 4*4 (IEEE 802.11ac, 1733Mbps)
Antenna : 6*External high gain antenna
Heat dissipation : Natural heat dissipation
Physical interface : 1*10/100/1000Mbps WAN (Auto MDI/ MDIX)
3*10/100/1000Mbps LAN (Auto MDI/ MDIX)
Indicator light : 2*Indicators
Reset button : 1*Reset button
Power input interface : 1*Power input interface
Wireless standard : IEEE802.11a/b/g/n/ac, IEEE 802.3/3u/3ab
Certification standards : GB/T9254-2008; GB4943.1-2011
Dual band : 2.4GHz/ 5GHz
Wireless channel :
•2.4GHz Channel: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
•5GHz Channel: 36, 40, 44, 48, 149, 153, 157, 161, 165
Modulation Mode :
11b: DSSS: DBPSK( 1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)
11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM(24/36Mbps), 64QAM(48/54Mbps)
11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0~MCS15
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM.
Rate set: MCS0~MCS9 (4 streams supported)
Operating system : Intelligent router operating system MiWiFi ROM based on OpenWRT deep customization
Wireless security : WPA-PSK / WPA2-PSK encryption, wireless access control (black and white list), hidden SSID, intelligent anti-scratch network
Management application : Support Web, Android, iOS

Working environment
Working temperature: 0~40℃
Storage temperature: 10%~90%RH Non-condensing
Working humidity: -40~70℃
Storage humidity: 5%~90%RH Non-condensing
Product size : 259mm*176mm*184mm (L*W*H)
