Ready MOTHERBOARD ECS ESSENTIALS H61H2-MV New Murah Bergaransi

Detail Ready MOTHERBOARD ECS ESSENTIALS H61H2-MV New Murah Bergaransi

Spesifikasi :
Brand : ECS
Model : ESSENTIALS H61H2-MV V1.0
CPU :
- Supports new 2nd & 3rd gen Intel" Core' family, Pentium, Celeron series processors in LGA 1155 socket
- DMI 5.0GT/s
- VRD 12.0
- Solid Capacitor for CPU side
CHIPSET :
- Intel" H61 Express Chipset
GRAPHICS :
- Support Intel" HD Graphics 2000/3000(Intel 2nd gen CPU) & 2500/4000(Intel 3rd gen CPU)
- Supports DirectX" 11
- Supports Intel" HD Graphics, InTru' 3D, Quick Sync Video, Clear Video HD Technology,
Insider'
MEMORY :
- Dual-channel DDR3 Memory architecture
- Supports DDR3 1600*/1333/1066 non-ECC, Un-buffered SDRAM Memory
- 2 X 240-pin DDR3 DIMM socket
- Support up to 16 GB*
EXPANSION SLOT :
- 1 X PCI Express X16 Gen 3.0 slot(s)
- 1 X PCI Express X 1 Gen 2.0slot(s)
STORAGE :
- Support by H61 Express Chipset
- 4 X Serial ATAII 3Gb/s
AUDIO :
- Realtek ALC662
LAN :
- Realtek 8111E Gigabit Fast Ethernet Controller
- (8105E 10/100Mbps Fast Ethernet Controller optional)
- Wake-On-LAN
USB :
- Support by H61 Express Chipset
- 8 X USB2.0 port(s) Up to 480 Mb/s
REAR PANEL I/O :
- 1 X PS/2 Keyboard & PS/2 mouse connectors
- 1 X Audio port (Line Out/Line In/Mic In)
- 1 X RJ-45 port
- 1 X D-Sub (VGA) port(s)
- 4 X USB2.0 port(s)
CONNECTORS & HEADERS :
- 1 X 24-pin ATX Power Supply connector
- 1 X 4-pin 12V Power connector
- 1 X 4-pin CPU_FAN connector
- 1 X 3-pin SYS_FAN connector
- 1 X Front panel audio header (90 degrees)
- 2 X USB 2.0 header
Support additional 4 USB ports :
- 4 X SATA II 3Gb/s connector(s)
- 1 X CLR_CMOS header
- 1 X Serial port header (COM)
- 1 X ME_UNLOCK header
FORM FACTOR :
- mATX Form Factor
- 195 mm(W) X 170mm(H)

Belanja di Sparta Computindo membuat Anda lebih Aman, Terpercaya, Dan tentunya Kepuasan Pelanggan yang menjadi Prioritas kami.
