RADIO RIG MARINE ICOM IC-M220 M220 VHF NEW GARANSI RESMI

Detail RADIO RIG MARINE ICOM IC-M220 M220 VHF NEW GARANSI RESMI

Deskripsi Produk : ICOM IC-M220 VHF MARINE

Output power (at 13.8 V DC) 25 W, 1 W
Max. frequency deviation ±5 kHz
Frequency tolerance ±5 ppm
Spurious emissions Less than –60 dBc

Receiver
Sensitivity Main –13 dBµ typ. (12 dB SINAD)
DSC –5 dBµ emf typ. (1% BER)
Squelch sensitivity Less than –10 dBμ
Adjacent channel
selectivity Main More than 68 dB
DSC More than 68 dBμ emf (1% BER)
Intermodulation Main More than 63 dB
DSC More than 55 dBμ emf (1% BER)
Sensitivity –14 dBμ typ. (at 12 dB SINAD)
Hum and noise More than 40 dB
Audio output power
(at 10% distortion with a 4 Ω load) 4.5 W

General
Frequency range TX 156.025–157.425 MHz
RX 156.050–163.275 MHz
CH70 156.525 MHz
Usable channels USA, CAN, INT, WX channels
Type of emission 16K0G3E (FM), 16K0G2B (DSC)
Power supply requirement 13.8 V DC nominal
(11.7–15.9 V DC)
Current drain
(at 13.8 V DC) TX 25W output 5 A
RX AF max. 1.2 A
Operating temperature range –20°C to +60°C; –4°F to +140°F
Antenna impedance 50 Ω(SO-239)
Dimensions (W×H×D)
(Projections not included) 156.5×66.5×110.1 mm;
6.2×2.6×4.3 inch
Weight (approx.) 700 g; 1.5 lb (with HM-237B)
NMEA formats Input RMC, GGA, GNS, GLL, VTG
Output DSC, DSE, RMC, GSA, GSV

Tambahan Packing BIar Tambah Aman :
https://shopee.co.id/BUBBLE-WRAP-TAMBAHAN-PACKING-BARANG-AGAR-LEBIH-AMAN-i.22497590.1856775339

Gambar produk
