Radial StageBug SB2 SB-2 Passive Direct Box DI BOX
Deskripsi singkat
Komputer & Aksesoris > Penyimpanan Data > Casing Hard Disk & Docking > Radial StageBug SB2 SB-2 Passive Direct Box DI BOX
Toko:Seven Stereo Music & Audio StoreLihat semua produk Komputer & Aksesoris oleh Seven Stereo Music & Audio Store
- Pengiriman Ekspres
- Barang yang diperiksa
- Bayar di tempat berlaku
- Kualitas, Prestise
- Pengembalian produk
- Dukung pembuatan faktur
Produk Terkait
Detail Radial StageBug SB2 SB-2 Passive Direct Box DI BOX
Circuit Type Passive, transformer basedNumber of Channels Single channel (mono)
Frequency Response 20 Hz to 20 kHz (0.5 dB)
Dynamic Range 115 dB
Maximum Input +20 dB
Total Harmonic Distortion 0.005% @ 1 kHz
Deviation Phase:
3 @ 100 Hz; 8 @ 50 Hz
Input Impedance 140 k, unbalanced
Output Impedance 1 k, balanced
Transformer Eclipse ET-DB3, 12:1 ratio
Shield Copper foil
Features Input Pad: -10 dB
Auto Merge: Sums left & right sources to mono
Ground Lift: Disconnects pin-1 at XLR output
XLR Configuration: AES standard (pin-2 hot)
Connectors 1/4" in & thru, XLR-M out
Construction 14-gauge steel chassis & outer shell
Finish Baked enamel
Dimensions (L x W x D) 4.50 x 1.85 x 1.35" (114.30 x 47.00 x 34.29 mm)
Gambar produk
